Instrument System Products

Supra Condylar Nail Instrument Set

1 - Jig Nail Connecting Handle - 1
2 - Distal Targeting Device - 1
3 - Nail Connecting Bolt Cannulated - 1
4 - Ram - 1
5 - Ram Rod - 1
6 - Top for Nail Connecting Bolt - 1
7 - Tomy Bar - 1
8 - Protection Sleeve Ø 10.0 x 8.0mm - 1
9 - Drill Sleeve Ø 8.0 x 4.0 mm - 1
10 - Wire Sleeve Ø 8.0 x 1.8mm - 1
11 - Washer -
12 - Wrench - 1
13 - Drill Bit - Non Coupling 4.0mm x 300 mm - 1
14 - Kuntscher's Diamond Pointed Awl- Curved - 1
15 - Trocar Ø 8.0mm - 1
16 - Screw Driver (Hexagonal) Ø 4.5mm for I.L - 1
17 - Guide Rod Ø 2.5mm x 95 cm - 1
18 - Reaming Rod with Olive Point Ø 2.5mm x 95cm - 1
19 - Instrument box - 1

Fusion Instruments System

1 - 445.136 - Fusion Instruments box - 1
2 - 445.137 - Cannulated Intervertebral Disc Reamer 7.5 * 6.5mm - 1
3 - 445.138 - Cannulated Intervertebral Disc Reamer 8.5 * 7.5mm - 1
4 - 445.139 - Cannulated Intervertebral Disc Reamer 9.5 * 8.5mm - 1
5 - 445.140 - Round Cannulated Curette (Scraper) 7.0mm - 1
6 - 445.141 - Round Cannulated Curette (Scraper) 8.0mm - 1
7 - 445.142 - Round Cannulated Curette (Scraper) 9.0mm - 1
8 - 445.143 - Bone Graft Impactor - 1
9 - 445.145 - PLIF Cage Trial 8*20.22.26 - 1
10 - 445.147 - PLIF Cage Trial 10*20.22.26 - 1
11 - 445.149 - PLIF Cage Trial 12*20.22.26 - 1
12 - 445.153 - PLIF CAGE Holder - Curved - 1
13 - 445.154 - Bone Graft Desk - 1
14 - 445.155 - Hammer - 1
15 - 445.157 - Nerve Root Retractor 135° * 8 - 1
16 - 445.158 - Nerve Root Retractor 135° * 4 - 1
17 - 445.160 - PLIF Cage Holder - Straight - 1
18 - 445.161 - Periosteum Nerve Stripper - 1
19 - 445.162 - Toothed Curette 8.0mm - 1
20 - 445.163 - Vertebral Plate Scraper (Push) 8.0mm - 1
21 - 445.164 - Cannulated Intervertebral Disc Reamer 10.5 * 10mm - 1
22 - 445.165 - Side Scraper 7.5mm - 1
23 - 445.166 - Side Scraper 10.0mm - 1
24 - 445.167 - Impactor - 1
25 - 445.168 - Intervertebral Disc Scraper (Bena Forward)8.0mm - 1
26 - 445.169 - Bone Graft Pusher - 1
27 - 445.170 - Nucleus Pulposus Chisel (ellipse)6.5*4.5 - 1
28 - 445.171 - Nucleus Pulposus Chisel (ellipse)8.5*6.5 - 1

CANNULATED SCREW INSTRUMENTINSTSYSTEM 6.5/7.3

1 - 445.600 CLEAN GUIDE PIN Ø2.5*250 - 1
2 - 445.601 SLEEVE FOR GUIDE PIN Ø2.5 - 1
3 - 445.602 SLEEVE FOR DRILL BIT Ø5 - 1
4 - 445.603 DILATOR Ø2.5 - 1
5 - 445.604 HOLDER - 1
6 - 445.605 TWO-HOLE GUIDER Ø2.5 - 1
7 - 445.606 MULTI-HOLE GUIDER - 1
8 - 445.607 CANNULATED DRILL BIT Ø5 - 1
9 - 445.608 CANNULATED TAP Ø7.3 - 1
10 - 445.609 CANNULATED COUNTERSINK DRILL - 1
11 - 445.610 CANNULATED SLEEVE SW6 - 1
12 - 445.611 SKID TAKE-OFF SW4 - 1
13 - 445.612 LIMITATOR FOR DRILL BIT - 1
14 - 445.613 LIMITED WRENCH SW3 - 1
15 - 445.614 CANNULATED SCREWDRIVER HEX SW4.0 - 1
16 - 445.615 SCREWDRIVER HEX SW4.0 - 1
17 - 445.616 SCREW HOLDER (HEX) Ø8 - 1
18 - 445.617 DEPTH GAUGE FOR GUIDE PIN Ø2.5 - 1
19 - 445.618 GUIDE PIN Ø2.5*250 - 5
20 - 445.619 GUIDE PIN WITH THREADS 2.5*250 - 5

CANNULATED SCREW INSTRUMENT SYSTEM 3.5/4.0/4.5

1 - 445.630 GUIDE PIN Ø1.5*150 - 5
2 - 445.631 GUIDE PIN WITH THREADS 1.5*150 - 5
3 - 445.632 DEPTH GAUGE FOR GUIDE PIN - 1
4 - 445.633 SLEEVE FOR GUIDE PIN Ø1.5/Ø3.2 - 1
5 - 445.634 SLEEVE FOR DRILL BIT Ø3.2 - 1
6 - 445.635 LIMITATOR WRENCH SW2.5 - 1
7 - 445.636 LIMITATOR FOR DRILL - 1
8 - 445.637 LIMITED CANNULATED DRILL BIT Ø3.2*150/Ø1.5 - 1
9 - 445.638 CANNULATED TAP Ø4.5/Ø1.5 - 1
10 - 445.639 CANNULATED COUNTERSINK DRILL - 1
11 - 445.640 CANNULATED SCREWDRIVER HEX SW2.5 - 1
12 - 445.641 SCREW HOLDER - 1
13 - 445.642 SKID TAKE-OFF SW2.5 - 1
14 - 445.643 SCREW DRIVER SLEEVE - 1
15 - 445.644 SCREWDRIVER HEX SW2.5 - 1
16 - 445.645 CLEAN GUIDE PIN Ø1.5*150 - 1

SPINE INSTRUMENT SYSTEM - IMPORTED

1 - 446.001 GUIDE PIN Ø 1.5 X 380 - 4

2 - 446.002 GUIDE PIN Ø 1.5 X 250 - 4

3 - 446.003 STRAIGHT PROBE/ BENDING PROBE - Each 1

4 - 446.004 MOULD BAR LENGTH 300/200/120 - Each 1

5 - 446.005 UPRIGHT QUICK REPLACEABLE WRENCH SHAFT HOLLOW - 1

6 - 446.006 HORIZONTAL QUICK REPLACEABLE WRENCH SHAFT - 1

7 - 446.007 BONE HAMMER - 1

8 - 446.008 POSITIONING DRILL SLEEVE - 2

9 - 446.009 TAMPER CLAMP DEVICE - 1

10 - 446.010 ANTI-TORSION WRENCH - 2

11 - 446.011 TAMPER CLAMP S3 - 1

12 - 446.012 BENDING ROD HOLDING FORCEPS S7 - 1

13 - 446.013 SNAP CLAMP Ø4 - 1

14 - 446.014 ROD CLAMP Ø5 - 1

15 - 446.015 POLY-AXIAL PLACKET PEDICLE SCREW WRENCH Ø6 - 2

16 - 446.016 PLACKET PEDICLE SCREW WRENCH - 1

17 - 446.017 SCREW TAP SOLID Ø 4 (INNER HOLE Ø1.6) - 1

18 - 446.018 SCREW TAP SOLID Ø 5 (INNER HOLE Ø2.1) - 1

19 - 446.019 SCREW TAP SOLID Ø 6 (INNER HOLE Ø2.1) - 1

20 - 446.020 HEXAGONAL SOCKET WRENCH S7 - 2

21 - 446.021 INNER HEXAGONAL WRENCH S3.5 - 1

22 - 446.022 LIMIT DRILL - 1

23 - 446.023 INNER HEXAGONAL WRENCH S5 - 2

24 - 446.024 INNER HEXAGONAL WRENCH S5 - 2

25 - 446.025 IMPLANTED INSTRUMENT OF DEVELOPING NEEDLE - 1 set

26 - 446.026 OPENING DRILL (SHORT) - 1

27 - 446.027 REAMING AWL STRAIGHT - 1

28 - 446.028 ROD BENDING CLAMP - 1

29 - 446.029 HORIZONTAL QUICK REPLACEABLE WRENCH SHAFT HOLLOW - 1

30 - 446.030 REAMING AWL BENDING - 1

31 - 446.031 DISTRACTION CLAMP STRAIGHT - 1

32 - 446.032 PERSUADER - 1

33 - 446.033 INNER HEXAGONAL WRENCH Ø 2.5 - 1

34 - 446.034 SCREW TAP SOLID Ø 3.5 - 1

DORSOLUMBER SPINAL IMPLANTS

ANTERIOR CERVICAL PLATE INSTRUMENTS SYSTEM

1 - 446.401 - Case+Screw Box - 1
2 - 446.402 - Plate Holder Forceps type - 1
3 - 446.407 - Drill Bit Φ2.5 - 1
4 - 446.659 - Hex Screw Driver SW2.5 - 2
5 - 446.404 - Hand Drill Bit Φ2.5 - 1
6 - 446.406 - Distractor Φ3.5/SW3.8 - 1
7 - 446.403 - Implanter of Location Screw - 1
8 - 446.413 - Curette - 1
9 - 446.415 - Locking Nail Screw driver - 1
10 - 446.405 - Plate Bender Wrench - 1
11 - 446.412 - Screw Driver Holder - 2
12 - 446.414 - Guider Φ2.5 - 1
13 - 446.408 - Hole Open Forceps Φ2*13 - 1
14 - 925.155 - Screw Holder - 1
15 - 925.145 - Plate Holder - 1

Pelvic Reduction Instrument System Imported

1 - 900.141 Reduction Forceps, Oblique,1#

2 - 900.142 Reduction Forceps, Oblique,2#

3 - 900.143 Pelvic Reduction Forceps with points

4 - 900.144 Bone Holding Forcep(Small)

5 - 900.145 Screw Driver(Hex) SW2.5 l ong

6 - 900.146 Bone Holding Forcep(Large)

7 - 900.147 Pelvice Reduction Forceps,1#

8 - 900.148 Pelvice Reduction Forceps,2#

9 - 900.149 Acetabulum Reduction Forceps

10 - 900.150 Loeatingdriver

11 - 900.151 Drill Bit 2.5 x 225mm

12 - 900.152 Combination Drill Guide

13 - 900.153 Plate Bending Wrench

14 - 900.154 Screw Tap 3.5 T-Handle

15 - 900.155 Reduction Forceps With 3Ball Tips

16 - 900.156 Sharp Hook

17 - 900.157 T-Sharp Hook

18 - 900.158 Plate Bonding Wrench

19 - 900.159 Universal Screw Driver

20 - 900.160 Hohmarn Retractor

21 - 900.161 Drill Guide Sleeve

Broken Screw Removal System Imported

1 - 900.217 - Forceps For Screw Removal - 200mm - 1
2 - 900.200 - Conical Extraction Screw - sw2.5*0.5 - 1
3 - 900.201 - sw2.5 - 1
4 - 900.203 - sw3.5 - 1
5 - 900.204 - sw4.0 - 1
6 - 900.174 - Extraction Bolt - 3.5 - 1
7 - 900.175 - 4.5 - 1
8 - 900.176 - 6 - 1
9 - 900.177 - 6.5 - 1
10 - 900.204 - 2.7 - 1
11 - 900.205 - 3 - 1
12 - 900.206 - 4 - 1
13 - 900.207 - 5 - 1
14 - 900.209 - 6.5 - 1
15 - 900.210 - 8 - 1
16 - 900.111 - 10 - 1
17 - 900.189 - Ao Hex Head Screwdrive Shaft - sw1.5 - 1
18 - 900.190 - sw2.0 - 1
19 - 900.191 - sw2.5 - 1
20 - 900.192 - sw3.0 - 1
21 - 900.193 - sw3.5 - 1
22 - 900.194 - sw4.0 - 1
23 - 900.195 - sw4.5 - 1
24 - 900.196 - Hollow Saw For Broken screw - sw5.0 - 1
25 - 900.197 - sw5.5 - 1
26 - 900.171 - 1.1mm - 1
27 - 900.172 - square Head Screwdrive - 1.2mm - 1
28 - 900.173 - 1.3mm - 1
29 - 900.181 - T2.3 - 1
30 - 900.182 - T2.7 - 1
31 - 900.183 - T3.2 - 1
32 - 900.184 - star Head Screwdrive - T3.4 - 1
33 - 900.185 - T3.8 - 1
34 - 900.186 - T4.3 - 1
35 - 900.187 - T5.3 - 1
36 - 900.179 - Flat Head Screwdrive - 1
37 - 900.180 - - 1
38 - 900.178 - cross Head Screwdrive - 1
39 - 900.226 - spine Screwdrive - 1
40 - 900.213 - Quick Change T Handle - 1
41 - 900.215 - Quick change Straight Handle - 1
42 - 900.227 - Handle with Quick Coupling - 8mm - 1
43 - 900.217 - Instrument For Removal Of Danmaged Screw - ϕ 3.5 - 1
44 - 900.216 - Instrument For Removal Of Danmaged Screw - ϕ 4.5 - 1
45 - 900.213 - Sharp Hook - ϕ 2.2 - 1
46 - 900.212 - Sharp Cone - 1
47 - 900.219 - Hss Drill Bit - ϕ 4 - 1
48 - 900.221 - ϕ 6 - 1
49 - 900.224 - ϕ 8 - 1
50 - 900.225 - Box - 1

DHS Instrument System

Pediatric DHS Instrument System

Dr. Vinay Paediatric Hip Fixation System

1 - 901.100 DHS Angle Guide with 135º

2 - 467.125 Guide Wire, Threaded- Ø 2.5 mm

3 - 902.200 DHS Tripple Reamer for Pediatric

4 - 902.205 T-Handle with Quick Coupling

5 - 901.115 Direct Measuring Device

6 - 902.210 DHS Impactor for Greens Barrel Plate

7 - 902.215 DHS Long Coupling Screw for Removal

8 - 902.220 DHS Insertion Screw with Sleeve

9 - 902.225 DHS Tap for Greens Barrel Plate- Ø 10.0mm

10 - 902.230 Centering Sleeve for DHS Tap

11 - 902.235 T. Wrench for DHS Screw

12 - 902.240 Centering Sleeve for DHS T.Wrench

I.L. TIBIA FEMUR INSTRUMENT SYSTEM WITH JIG

1 - 903.100 - PROXIMAL COMBINED JIG FOR TIBIA/FEMUR - 1
2 - 903.105 - INSERTION DRIVING HEAD - 1
3 - 903.110 - RAM - 1
4 - 903.115 - RAM ROD - 1
5 - 903.120 - WRENCH - 1
6 - 903.205 - WIRE SLEEVE Ø 8.0 X 1.8MM - 1
7 - 903.122 - NAIL CONNECTING BOLT - 1
8 - 903.125 - PROTECTION SLEEVE Ø 10.0 X 8.0MM - 1
9 - 903.130 - DRILL SLEEVE Ø 8.0 X 4.0 MM - 1
10 - 903.135 - TROCAR Ø 8.0MM - 1
11 - 426.140 - DRILL BIT Ø 4.0MM X 225 MM- NON COUPLING - 1
12 - 401.100 - KUNTSCHER'S DIAMOND POINTED AWL- CURVED - 1
13 - 903.145 - TISSUE PROTECTOR - 1
14 - 903.150 - DEPTH GUAGE FOR INTERLOCKING- Ø 4.9MM - 1
15 - 439.500 - SCREW DRIVER (HEXAGONAL) Ø 4.5MM FOR I.L - 1
16 - 903.155 - GUIDE WIRE HOLDER - 1
17 - 903.160 - GUIDE ROD Ø 2.5MM X 95 CM - 1
18 - 903.165 - REAMING ROD WITH OLIVE POINT Ø 2.5MM X 95CM - 1
19 - 903.170 - ALUMINIUM BOX WITH TRAY - 1
20 - 903.175 - NAIL/ DRILL GUIDE BAR FOR TIBIA- OPTIONAL - 1
21 - 903.180 - DRILL GUIDE BAR FOR TIBIA / DISTAL JIG- OPTIONAL - 1
22 - 903.185 - NAIL/ DRILL GUIDE BAR FOR FEMUR- OPTIONAL - 1
23 - 903.190 - DRILL GUIDE BAR FOR FEMUR/ DISTAL JIG- OPTIONAL - 1

Humerus nail instruments system

1. 904.100 insertion handle for uhn

2. 901.110 connecting screw for uhn cannulated

3. 904.140 protection sleeve 11.0x 8.0mm

4. 904.150 trocar 8.0mm

5. 904.145 drill sleeve 8.0x 2.7mm

Instrument Set for ACL/PCL Screw

1 - 906.005 ACL PCL ZIG - 1
2 - 906.010 Graft passing 2.4mmdrillbit - 1
3 - 906.020 Graft passing pin (Beadth pin) - 1
4 - 906.060 Cannulated Tibial Reamer, Dia.6.0mm - 1
5 - 906.070 Cannulated Tibial Reamer, Dia.7.0mm - 1
6 - 906.080 Cannulated Tibial Reamer, Dia.8.0mm - 1
7 - 906.090 Cannulated Tibial Reamer, Dia.9.0mm - 1
8 - 906.100 Cannulated Tibial Reamer, Dia.10.0mm - 1
9 - 906.110 Cannulated Tibial Reamer, Dia.11.0mm - 1
10 - 906.120 Cannulated Tibial Reamer, Dia.11.0mm - 1
11 - 906.160 Cannulated Femoral Flowertip Reamer, Dia.6.0mm - 1
12 - 906.170 Cannulated Femoral Flowertip Reamer, Dia.7.0mm - 1
13 - 906.180 Cannulated Femoral Flowertip Reamer, Dia.8.0mm - 1
14 - 906.190 Cannulated Femoral Flowertip Reamer, Dia.9.0mm - 1
15 - 906.200 Cannulated Femoral Flowertip Reamer, Dia.10.0mm - 1
16 - 906.210 Cannulated Femoral Flowertip Reamer, Dia.11.0mm - 1
17 - 906.220 Cannulated Femoral Flowertip Reamer, Dia.12.0mm - 1
18 - 906.230 Cannulated Endoscopic Reamer,dia.4.5mm - 1
19 - 906.235 Depth Gauge for ACL/PCL reconstruction - 1
20 - 906.240 Femoral Aimer,5mm - 1
21 - 906.245 Femoral Aimer,7mm - 1
22 - 906.250 Tunnel Plug, 7-8 mm - 1
23 - 906.255 Tunnel Plug, 8-9 mm - 1
24 - 906.260 Tunnel Plug, 9-10 mm - 1
25 - 906.265 Tunnel Dilator,7mm - 1
26 - 906.270 Tunnel Dilator,8mm - 1
27 - 906.275 Tunnel Dilator,9mm - 1
28 - 906.280 T-Handle for Tunnel Dilators - 1
29 - 906.285 Cannulated screwdriver for BioLoc interference screws - 1
30 - 906.290 Impactor for spiked ligament staple - 1
31 - 906.295 Arthroscopic Probe - 1
32 - 906.300 Microfracture Awl,30’ - 1
33 - 906.305 Microfracture Awl,45’ - 1
34 - 906.310 Microfracture Awl,90’ - 1
35 - 906.315 Graft Prep Station - 1
36 - 906.320 Graft Sizing Block - 1
37 - 906.325 Tendon Stripper,Closed end,6mm - 1
38 - 906.330 Tendon Stripper,Open end,7mm - 1
39 - 906.335 Straight Rasp - 1
40 - 906.340 Convex Rasp - 1
41 - 906.345 Femoral PCL Elevator - 1
42 - 906.350 Graphic Case for Knee Arthroscopy Instruments - 1

Staple Instruments Set

1 - 925.201 - Staple Starter 15.0mm - 1
2 - 925.202 - Staple Starter 20.0mm - 1
3 - 925.203 - Staple Starter 25.0mm - 1
4 - 925.204 - Staple Impactor - 1
5 - 925.205 - Staple Inserter - 1
6 - 925.206 - Staple Extractor - 1
7 - 925.207 - Staple Opener - 1
8 - 925.208 - Staple Inserter/ Impactor - 1
9 - 925.200 - Staple Instruments Box - 1
